Discover the H-1™ Pro Series Compass E-Bike: The Ultimate Adventure Ride

Picture an electric mountain bike that doesn’t just carry you from point A to point B, but opens up a world of thrilling off-road adventures. That’s precisely what the H-1™ Pro Series Compass E-Bike delivers, with its perfect blend of power, control, and rugged durability. Engineered for riders who demand peak performance and limitless exploration, this cutting-edge machine rewrites the rules of what an e-bike can do. Get ready to dive deep into the features, specs, and jaw-dropping capabilities that set the Compass in a class of its own.

H-1 Pro Series Compass Overview

Breaking the Boundaries of What’s Possible

The H-1 Pro Series Compass is no ordinary electric bicycle; it’s a finely tuned, trail-hungry beast designed for riders who live to push limits. With an MSRP of $2,000, this premium e-MTB delivers exceptional value, outperforming models that cost significantly more. Its unrivaled combination of a high-torque mid-drive motor, expansive battery capacity, and mountain-ready components make it the perfect choice for adrenaline junkies and weekend warriors alike.

Versatility for Every Skill Level

While the Compass boasts serious off-road chops, it’s also incredibly adaptable and user-friendly. Beginner riders will appreciate the smooth, intuitive pedal assist that helps flatten hills and extends endurance. Meanwhile, experienced cyclists will relish the bike’s ability to conquer technical terrain and reach blistering speeds. No matter your skill level or riding style, the Compass has the power and finesse to elevate your experience.

Core Specifications

Feature	Specification
Frame Material	High-grade aluminum alloy
Motor Type	Mid-drive
Motor Power	500W continuous, 750W peak
Torque	80 Nm
Battery	Removable 48V 14Ah (672 Wh) lithium-ion
Range	Up to 51 miles pedal-assist, 31 miles throttle-only
Charging Time	5-6 hours
Top Speed	20 MPH (32 km/h)
Brakes	Dual hydraulic disc, 180mm front/160mm rear rotors
Tires	27.5″ x 2.4″ Maxxis Minion DHF pneumatic
Drivetrain	Shimano Deore 10-speed
Suspension	RockShox Recon 140mm travel fork
Display	Full-color LCD with USB charging
Weight	55.8 lbs (25.3 kg)
Maximum Payload	264 lbs (120 kg)

Powertrain

500W Mid-Drive Motor: Conquer Any Climb

The heart of the Compass’s impressive performance lies in its state-of-the-art 500W mid-drive motor. Manufactured by Bafang, a leader in e-bike propulsion, this powerhouse delivers a continuous output of 500 watts with a peak rating of 750W. That translates to an incredible 80 Nm of torque – more than enough to sail up steep inclines and power through challenging obstacles.

Why opt for a mid-drive over a hub motor? Several key advantages make mid-drives the preferred choice for serious off-road riding:

• Optimal weight distribution: With the motor positioned at the center of the bike, the Compass maintains a low, balanced center of gravity. This results in superior handling and stability, especially when navigating technical terrain or tight corners.
• Increased efficiency: By leveraging the bike’s gears, the motor operates at peak efficiency across a wide range of speeds and gradients. You’ll enjoy snappy acceleration, consistent power delivery, and extended range compared to hub-driven systems.
• Reduced wear and tear: Since the motor drives the crank rather than the wheel directly, there’s less stress on the rear hub, spokes, and rim. This leads to improved durability and lower maintenance costs over time.

The Compass’s Bafang motor also features an integrated torque sensor that measures your pedaling force and adjusts assist levels accordingly. This creates an incredibly natural, responsive riding experience – it’s like having bionic legs propelling you forward.

Advanced Motor Controller and Regenerative Braking

Complementing the Bafang motor is a sophisticated controller that regulates power output and optimizes efficiency. The Compass utilizes a sinewave controller, known for its smooth, jolt-free performance. You’ll appreciate the seamless transitions between assist levels and the precise control over your speed.

Another standout feature is the controller’s regenerative braking capability. When engaged, the motor acts as a generator, converting kinetic energy from deceleration back into electricity to recharge the battery. This not only extends your range but also reduces wear on the brake pads for lower maintenance.

Braking and Suspension

Dual Hydraulic Disc Brakes for Ultimate Stopping Power

To reign in the Compass’s formidable speed and maintain control on steep descents, the bike is outfitted with a set of dual hydraulic disc brakes. This premium braking system offers several advantages over mechanical discs or rim brakes:

• Increased stopping power: Hydraulic systems deliver superior clamping force compared to cable-actuated brakes, providing shorter stopping distances and better modulation.
• Consistent performance: Unlike cables that can stretch and degrade over time, the sealed hydraulic fluid provides reliable, fade-free braking in all conditions.
• Low maintenance: With no cables to adjust or replace, hydraulic brakes require minimal upkeep to maintain optimal performance.

The Compass features robust 180mm rotors up front and 160mm rotors in the rear. These large diameter discs provide ample surface area for rapid heat dissipation, resisting brake fade on long, demanding descents. The brake calipers use high-performance ceramic pads that strike an ideal balance between stopping power, durability, and noise reduction.

RockShox Recon Suspension Fork

To tame rough terrain and enhance control, the Compass boasts a RockShox Recon suspension fork with 140mm of travel. This air-sprung fork is a favorite among trail riders for its smooth, adjustable performance and reliability. Key features include:

1. Solo Air spring: RockShox’s proprietary air spring design allows you to easily tune the fork to your weight and riding style with a shock pump. The progressive spring rate provides a plush initial stroke for small bumps and a firmer ramp-up for big hits.
2. Rebound adjustment: Dial in the fork’s rebound damping to control how quickly it extends after compression. Faster rebound keeps the front wheel glued to the ground for traction, while slower rebound enhances comfort and stability.
3. Lockout switch: For smooth fire roads or pavement, a simple lockout switch stiffens the fork to eliminate unwanted suspension movement and maximize pedaling efficiency.

The Recon’s beefy 35mm stanchions and Boost spacing provides ample stiffness for precise steering input and stability at high speeds. A series of protective measures, including wiper seals and anodized finishes, keep the fork running smoothly through rain, mud, and grit.

Frame and Components

Lightweight, Durable 6061 Aluminum Frame

At the core of the Compass’s rugged yet nimble character is its high-grade 6061 aluminum frame. This heat-treated alloy, commonly found in aircraft and performance vehicles, offers an excellent strength-to-weight ratio. The frame’s oversized tubing profiles and advanced hydroforming process create a stiff, responsive chassis that can withstand the rigors of aggressive riding.

To fine-tune the riding dynamics, the Compass’s frame features:

• Slack head tube angle: A slack 66-degree head angle elongates the wheelbase for increased stability at speed while providing more relaxed, confidence-inspiring handling on steep descents.
• Steep seat tube angle: The steep 75-degree seat tube puts the rider in a more upright pedaling position for optimal power transfer and front-end control when climbing.
• Long reach, short stem: A roomy cockpit paired with a stubby stem creates a balanced riding position that blends agility with high-speed stability.

Internal cable routing and a sleek motor integration give the Compass a clean, streamlined appearance while protecting sensitive components from the elements. The tapered head tube and thru-axle dropouts increase front-end stiffness and precise wheel tracking for predictable handling in rough terrain.

Maxxis Minion DHF 27.5+ Tires

Wrapping the Compass’s sturdy wheels is a set of plus-sized Maxxis Minion DHF 27.5 x 2.4″ tires. These aggressive all-terrain treads are a favorite among downhill and enduro racers for their exceptional cornering grip and braking traction. The DHF’s key features include:

• Ramped center knobs: The center tread features alternating ramped and unramped knobs to reduce rolling resistance and provide straight-line control.
• Beefy side knobs: Tall, heavily siped side knobs claw into loose terrain for unshakable traction during hard cornering.
• EXO sidewall protection: Maxxis’s EXO casing fends off punctures and sidewall slices from jagged rocks and trail debris.

The high-volume 2.4″ width provides a larger contact patch for improved grip and stability, while the pliable sidewalls deform around obstacles for a smoother, more consistent ride feel. Set up tubeless, the Minion DHFs allow you to run lower tire pressures for maximum traction and comfort without risk of pinch flats.

Shimano Deore 10-Speed Drivetrain

To transfer the Compass’s prodigious power to the trail, the bike employs a rugged Shimano Deore 10-speed drivetrain. This workhorse group balances performance, reliability, and value, making it a smart spec for hard-charging e-MTBs. Key drivetrain components include:

• Deore M6000 shifter: The ergonomic Rapid Fire Plus shift lever provides crisp, precise gear changes with minimal effort.
• Deore M6000 derailleur: The Shadow RD+ design tucks the derailleur close to the frame for increased clearance and stability over rough terrain. An adjustable clutch mechanism maintains chain tension to eliminate dropped chains and reduce noise.
• 11-46t cassette: The wide-range 10-speed cassette provides ample low-end gearing for steep climbs while maintaining tight spacing for smooth, consistent cadence.

With its bombproof construction and smooth, reliable performance, the Deore drivetrain is built to withstand the added torque and abuse that e-MTBs inevitably dish out.

Rider Interface and Accessories

Full-Color LCD Display

Commanding the Compass’s advanced electronics is a vibrant, full-color LCD display. This large, centrally mounted screen provides a wealth of ride data at a glance, including:

• Current speed
• Trip distance and odometer
• Battery level percentage and bar graph
• Pedal assist level
• Watt output

The display’s intuitive controls allow you to toggle between assist levels, activate the headlight, and reset trip meters with the push of a button. Its adjustable backlight ensures clear visibility in any light conditions, from pre-dawn starts to dusky returns.

USB Charging Port and Smartphone Companion App

For added convenience, the Compass’s display integrates a USB charging port, allowing you to top off your smartphone or GPS device on the go. With power always at hand, you can confidently navigate new trails, snap photos, and stay connected without fear of a drained battery cutting your ride short.

To further enhance your experience, H-1’s smartphone companion app syncs with the Compass to provide advanced features and customization options:

• Fine-tune assist levels and power output to match your riding style
• Record and analyze ride data, including GPS tracks, elevation profiles, and performance metrics
• Diagnose and troubleshoot error codes for streamlined maintenance
• Receive over-the-air firmware updates to keep your bike running at its best

The app’s user-friendly interface and robust suite of tools make it an indispensable companion for data-hungry riders and tech enthusiasts.

Integrated Front and Rear Lights

For added safety and convenience, the Compass comes equipped with integrated front and rear LED lights. The powerful headlight illuminates the trail ahead, allowing you to extend your adventures into the early morning or evening hours. Meanwhile, the red taillight increases visibility to other trail users and vehicles, providing an extra measure of safety in low-light conditions.

The lights run off the main battery pack, so you never need to fuss with replacing batteries or remembering to charge separate devices. An ambient light sensor automatically adjusts the headlight’s brightness based on conditions, conserving battery power in daylight and ramping up output as darkness falls.
